Main page » Products » ESD Protection » ESD Flooring » Accessories for floor coverings » Special adhesive K192 conductive

Special adhesive K192 conductive

(Product No.: 1280.K192)

(Product No.: 1280.K192)

Special adhesive K192 conductive

ArticleNo: 1280.K192

dpvlink:

10266

Large container:

13 kg

Properties:

ESD-protective

Further product information

Minimum order:

13 KGM

Availability: at short notice

at short notice

at short notice

13,30 EUR

13 KGM

Product Info

The specialty adhesive K192 is characterized by its conductive properties and low-emission composition. This fiber-reinforced dispersion specialty adhesive is available in light gray color and is specifically designed for use with conductive PVC coverings in rolls and tiles, as well as rubber coverings up to a thickness of 4 mm (rolls) or 2.5 mm (tiles).
The application of K192 is particularly recommended on cross-conductive prepared subfloors, such as those treated with Thomsit R762 Conductive Finish. For rubber coverings, absorbent substrates without conductive finish are suitable. The adhesive is ideal for spaces where strict hygienic and safety requirements exist, such as operating and computer rooms, laboratories, and areas at risk of explosions in production and storage.
The adhesive is supplied in large containers of 13 kg and should be applied with a notched trowel at a consumption rate of about 280g/m². It is temperature resistant from 10 to 30 °C, allowing flexible use under various environmental conditions.

Details

Large container Large container: 13 kg
Color Color: light grey
Conductivity Conductivity: conductive
Temperature resistance Temperature resistance: 10 - 30 °C

ESD protective

Pictograms

ESD protective

Electrostatic Discharge - marking for materials intended to protect other components from ESD by avoiding potential differences.

Documents

Downloads

Please log in to download datasheets! :: There are several datasheets for this product. Please log in!
