DC1160 Digital dispenser - max. 6 bar
The DC1160 digital dosing device from Vieweg enables precise control of pneumatically controlled dosages and is ideal for applications with 3 – 55cc micro cartridges. With a maximum pressure of 6 bar and a dosing duration from 0.01 to 999 seconds, the device combines flexibility with efficiency in material processing.
The unit is equipped with a precision pressure regulator and digital pressure monitoring, which allows precise control of the pressure on the material and displays it on the backlit screen. Additional operational safety is ensured by EMC safety and the digital display of vacuum retention.
The compact design with dimensions of 260 x 75 x 220 mm and a weight of 1.5 kg makes the device particularly handy. It comes with an extensive accessory kit that includes a foot switch, a cartridge holder, a connection hose for the compressed air input, and various cartridges and dispensing needles.
Technically, the device supports an input voltage of 85-264 V AC and operates with a working voltage of 24 V DC. With a total of 8 programmable slots, the DC1160 dosing device offers high adaptability for various applications.
The unit is equipped with a precision pressure regulator and digital pressure monitoring, which allows precise control of the pressure on the material and displays it on the backlit screen. Additional operational safety is ensured by EMC safety and the digital display of vacuum retention.
The compact design with dimensions of 260 x 75 x 220 mm and a weight of 1.5 kg makes the device particularly handy. It comes with an extensive accessory kit that includes a foot switch, a cartridge holder, a connection hose for the compressed air input, and various cartridges and dispensing needles.
Technically, the device supports an input voltage of 85-264 V AC and operates with a working voltage of 24 V DC. With a total of 8 programmable slots, the DC1160 dosing device offers high adaptability for various applications.
Details
- Input voltage Input voltage
- 85 - 264 V/AC
- Working voltage Working voltage
- 24 V/DC
- Height [mm] Height [mm]
- 75 mm
- Length [mm] Length [mm]
- 220 mm
- Width [mm] Width [mm]
- 260 mm
- Compressed air input Compressed air input
- 5 - 7 bar
- Compressed air output Compressed air output
- 0,08 - 6 bar
- Dispensing method Dispensing method
- manuel / time-controlled
- Time range Time range
- 0.01 - 999 s
- Weight Weight
- 1.5 kg
Show accessories
Spares
Downloads
- Please log in to download datasheets! :
- There are several datasheets for this product. Please log in!
Catalogues
Product Family
Article image
Article description
Input voltage
Working voltage
Height [mm]
Length [mm]
Width [mm]
Compressed air input
Compressed air output
Price
Compare
85 - 264 V/AC
24 V/DC
75 mm
220 mm
260 mm
5 - 7 bar
0,08 - 2 bar
85 - 264 V/AC
24 V/DC
75 mm
220 mm
260 mm
5 - 7 bar
0,08 - 4 bar
85 - 264 V/AC
24 V/DC
75 mm
220 mm
260 mm
5 - 7 bar
0,08 - 6 bar
