The image displays a gray plastic mold with 15 rectangular indentations. It measures 555 mm in width and 355 mm in height, with a depth of 77 mm.
Vacuum-formed insert T-236 555 x 355 x 47 mm, 20 compartments ESD
(Product No.: 032.T-236)
The image displays a gray plastic mold with 15 rectangular indentations. It measures 555 mm in width and 355 mm in height, with a depth of 77 mm.
Notice

Vacuum-formed insert T-236 555 x 355 x 47 mm, 20 compartments ESD

Vacuum-formed insert T-236 555 x 355 x 47 mm, 20 compartments ESD

dpvlink:
18908
Length :
555 mm
Width [mm]:
355 mm
Height [mm]:
47 mm
Properties:
Further product information
Imprinting / Printing for boxes
Configure now


Minimum order:
10 PCE
available available
18,55 EUR

excl. 19% tax

10 PCE
Compare Compare
Notice
Product Info

Vacuum-formed insert T-236 555 x 355 x 47 mm, 20 compartments ESD

The deep-drawing insert T-236 from Licefa is specifically designed for the storage and transport of sensitive electronic components. With dimensions of 555 x 355 x 47 mm and 20 compartments each measuring 77 x 59 x 34 mm, it offers optimal use of space in containers sized 600 x 400 mm. This insert is characterized by its electrical conductivity, which complies with the standards DIN EN 61340-5-1, with a surface resistance between 10^3 and 10^5 Ohm.
The practical reversible stacking and the integrated handle recess facilitate handling and transport. The material Liastat guarantees safe storage through its ESD protection function, which prevents electrostatic discharges and thus ensures the integrity of the stored components. Ideal for technical purchasers looking for a reliable solution to protect sensitive electronics.
Length
Length
555 mm
Width [mm]
Width
355 mm
Height [mm]
Height
47 mm
Conductivity
Conductivity
conductive
Surface resistance Rs
Surface resistance Rs
103 - 105 Ω
Cavities
Cavities
20
Dimensions cavities
Dimensions cavities
77x59x34 mm
Suitable for containers
Suitable for containers
600x400 mm
Common
Vacuum-formed inserts are specially shaped inserts or inserts made of plastic that are used in storage and transport containers to store sensitive or fragile items safely and securely.
Licefa's ESD vacuum-formed inserts offer a first-class solution for the safe and efficient storage of your sensitive electronic components. All inserts are made of electrically conductive material (Liastat).

Pictograms
ESD protective
Electrostatic Discharge - marking for materials intended to protect other components from ESD by avoiding potential differences.

Documents

Downloads

Please log in to download datasheets! :
There are several datasheets for this product. Please log in!

Catalogues

Page: 317
Complete Catalog 2023 - 2024
Configurators:
Imprinting / Printing for boxes

Product Family

Vacuum-formed inserts T-236

Article image
Article description
Length
Width [mm]
Height [mm]
Price
Compare
032.T-236 - Vacuum-formed insert T-236 555 x 355 x 47 mm, 20 compartments ESD
032.T-236
Vacuum-formed insert T-236 555 x 355 x 47 mm, 20 compartments ESD
555 mm
355 mm
47 mm
18,55 EUR
Show Compare List (0)
