Quickfill magazine PS-7060
Quickfill magazine PS-7060
The Quickfill Magazine PS-7060 is distinguished by its stable and robust plastic construction with metal reinforcement, ensuring a long lifespan without wear of moving parts. It is compatible with the most common placement machines and offers a capacity for 50 PCBs. The width adjustment is made via quick-release adjustment, which allows for secure fixation of the set PCB widths.The dimensions of the magazine are 460 x 535 x 570 mm (W x D x H), and it can accommodate PCBs with a width of 50 to 390 mm. The plastic parts are made of conductive PS, which is temperature resistant up to 60°C, while the metal parts are made of galvanized iron. Additionally, the magazine is electrostatically dissipative.
The slot spacing is 10 mm, the slot width is 5 mm, and the slot depth is 3.5 mm. The product is delivered unassembled in a box, including assembly instructions, which facilitates transport and storage.
Details
- Width [mm] Width [mm]
- 460 mm
- Length [mm] Length [mm]
- 535 mm
- Height [mm] Height [mm]
- 570 mm
- PCB width PCB width
- 50 - 390 mm
- Width adjustment Width adjustment
- with quick-clamping adjustment
- Temperature resistance Insertion Temperature resistance Insertion
- 60 °C
- Material Material
- polystyrene
- Groove depth Groove depth
- 3.5 mm
- Groove width Groove width
- 5 mm
- Type Type
- unassembled
ESD protective
Electrostatic Discharge - marking for materials intended to protect other components from ESD by avoiding potential differences.
