The image shows an elongated, gray device with a blue label. It has two small LED lights in different colors and is intended for wall mounting.
fusION - Mini Ionizer
(Product No.: 7500.FU)
The image shows an elongated, gray device with a blue label. It has two small LED lights in different colors and is intended for wall mounting.

fusION - Mini Ionizer

fusION - Mini Ionizer

dpvlink:
7899
Further product information

at short notice at short notice

Compare Compare
Notice / Inquire
Product Info

fusION - Mini Ionizer

The fusION Mini Ionizer is a compact ionization device specifically designed for use in tight spaces such as machinery. It is ideally suited for applications such as pick-and-place machines and wave soldering, where electrostatic charges need to be neutralized.

Miniature Size: With dimensions of 7.5 x 4.8 x 8.9 cm, it is suitable for tight spaces.

Ionization: High-frequency alternating current (HF-AC) for efficient ionization.

Self-balanced Ion Balance: Ensures precise neutralization without additional manual calibration.

Multiple Linking: Up to four devices can be interconnected.

Fan Unit: Optional fan unit can be retrofitted to improve ionization in specific applications.

Integration: High voltage is generated directly within the device, minimizing external controls.

Emitter Tips: Made of tungsten (ISO 6 / Cleanroom Class 1000) for durability and effectiveness.

ISO according to 14644-1
ISO according to 14644-1
6
Height
Height
48 mm
Length
Length
89 mm
Width
Width
75 mm
Emitter material
Emitter material
tungsten
Show accessories
Accessories

Accessories

The image shows a small, square fan. It has a black rotor in the center and a light, rectangular frame with four mounting holes in the corners.
Blower pluggable, 40 x 40 x 10 mm for mini...
fusION - blower attachable 40 x 40 x 10 mm
Power supply via device
dpvlink
30121

Price on request
Documents

Downloads

Please log in to download datasheets! :
There are several datasheets for this product. Please log in!

Product Family

fusION - Mini Ionizer

Article image
Article description
ISO according to 14644-1
Height
Length
Width
Emitter material
Price
Compare
7500.FU - fusION - Mini Ionizer
7500.FU
fusION - Mini Ionizer
6
48 mm
89 mm
75 mm
tungsten
-
Show Compare List (0)

This product is similar to:

The image displays a rectangular, gray housing part with two green LEDs and an opening. At the top, there is a square fan with a black blade surface.
Power supply unit 230V AC / 24V DC for mini...
fusION - power supply unit 230V/50Hz to 24V DC
for max. 4 devices
dpvlink
30121

Price on request
The image shows a small, square fan. It has a black rotor in the center and a light, rectangular frame with four mounting holes in the corners.
Blower pluggable, 40 x 40 x 10 mm for mini...
fusION - blower attachable 40 x 40 x 10 mm
Power supply via device
dpvlink
30121

Price on request
