The image shows a compact, white chest of drawers with four drawers. The drawers have simple, straight metal handles. An empty shelf is visible on top.
Drawer unit LMC-04 ESD
(Product No.: LMC-04ESD)
The image shows a compact, white chest of drawers with four drawers. The drawers have simple, straight metal handles. An empty shelf is visible on top.
Notice

Drawer unit LMC-04 ESD

Drawer unit LMC-04 ESD

dpvlink:
1601
Width :
370 mm
Height :
455 mm
Depth :
460 mm
Drawers:
4
Load capacity :
15 kg
suitable for system:
TPH, WB, QuatreX, TPB
Properties:
Further product information
Treston Configurator
Configure now


available available
601,75 EUR

excl. 19% tax

1 PCE
Compare Compare
Notice
Product Info

Drawer unit LMC-04 ESD

The Treston LMC-04 ESD drawer unit is an efficient solution for work environments with limited space. This model is distinguished by its modern design, featuring rounded front panels and handles that are not only functional but also aesthetically pleasing. The unit is made of powder-coated steel and has an MDF panel on the front, ensuring a sturdy and durable construction.
The dimensions of the drawer unit are 460 mm in depth, 370 mm in width, and 455 mm in height. Each of the four drawers has a height of 100 mm and a load capacity of about 15 kg. The internal dimensions of the drawers are 278 mm in width, 75 mm in height, and 438 mm in depth. The drawers are equipped with glide rails that allow an opening up to 75% and feature a central locking system to secure the contents.
The drawer unit is specifically designed for integration into TP, TPH, and WB series workbenches. For optimal adaptation to WB tables, the additional holder LMCK 2 is required.
Width
Width
370 mm
Height
Height
455 mm
Depth
Depth
460 mm
Drawers
Drawers
4
Load capacity
Load capacity
15 kg
suitable for system
suitable for system
TPH, WB, QuatreX, TPB
Color
Color
light grey
Drawer height
Drawer height
100 mm
Internal depth
438 mm
Internal height
75 mm
Internal width
Internal width
278 mm
Material
Material
steel
Surface
Surface
Epoxy powder-coated
ESD
ESD
yes
Version
Version
70% extension
Pictograms
ESD protective
Electrostatic Discharge - marking for materials intended to protect other components from ESD by avoiding potential differences.

Documents

Downloads

Please log in to download datasheets! :
There are several datasheets for this product. Please log in!

Catalogues

Page: 261
Complete Catalog 2023 - 2024
Configurators:
Treston Configurator

Product Family

Drawer unit LMC

New narrow drawer unit series. Modern industrial design. They are ideal for limited place capacities. The front walls and the handles are rounded. Load capacity approx. 15 kg per drawer

  • Drawer height 100 mm
  • Slide rails up to 75% opening
  • Holder, central locking
  • powder-coated sheet steel, RAL 7035
  • Front wall made with MDF board
  • Suitable for work tables of the series TP, TPH, and WB.

For WB tables we recommend the models LMC 01/LMC-02 ESD. The holder LMCK 2 is required for mounting on WB tables.


Article image
Article description
Width
Height
Depth
Drawers
Load capacity
suitable for system
Price
Compare
LMC-01ESD - Drawer unit LMC-01 ESD
LMC-01ESD
Drawer unit LMC-01 ESD
370 mm
135 mm
460 mm
1
15 kg
TP, TPH, WB, TPB
268,20 EUR
LMC-02ESD - Drawer unit LMC-02 ESD
LMC-02ESD
Drawer unit LMC-02 ESD
370 mm
245 mm
460 mm
2
15 kg
TP, TPH, WB, TPB
429,05 EUR
LMC-04ESD - Drawer unit LMC-04 ESD
LMC-04ESD
Drawer unit LMC-04 ESD
370 mm
455 mm
460 mm
4
15 kg
TPH, WB, QuatreX, TPB
601,75 EUR
LMC-04-DESD - Drawer unit LMC-04-D ESD
LMC-04-DESD
Drawer unit LMC-04-D ESD
370 mm
455 mm
460 mm
1
15 kg
TP, TPH, WB, TPB
465,70 EUR
LMCK-2 - Cover LMCK 2
LMCK-2
Cover LMCK 2





WB, WTR
18,95 EUR
Show Compare List (0)
