Dissipative packaging bags DPV-3000 Zip 250 x 300 x 0.10 mm
The resealable packaging bags of type DPV-3000 Zip are ideal for technical applications where protection against electrostatic discharge is required. These bags measure 250 x 300 x 0.10 mm and are made from polyethylene, making them both amine-free and halogen-free. Their pink and transparent color as well as the dissipative property comply with the ESD standard DIN EN 61340-5-1, with a surface resistance of less than 10^11 Ω.
The bags are resealable thanks to a practical zip closure and offer a quick discharge time of maximum 2 seconds. They are also recyclable and carry standard prints such as type designation, ESD warning symbol, and LOT number. Each box contains 1000 pieces, which are durable for up to 3 years at an ambient temperature of over 23 °C and a humidity of more than 20%, provided they are stored properly. These features make the bags a safe and environmentally friendly choice for the storage and transport of sensitive electronic components.
The bags are resealable thanks to a practical zip closure and offer a quick discharge time of maximum 2 seconds. They are also recyclable and carry standard prints such as type designation, ESD warning symbol, and LOT number. Each box contains 1000 pieces, which are durable for up to 3 years at an ambient temperature of over 23 °C and a humidity of more than 20%, provided they are stored properly. These features make the bags a safe and environmentally friendly choice for the storage and transport of sensitive electronic components.
Details
- Width [mm] Width [mm]
- 250 mm
- Length [mm] Length [mm]
- 300 mm
- Thickness [mm] Thickness [mm]
- 0.1 mm
- Pcs/box Pcs/box
- 1000
- reclosable reclosable
- yes
- Color Color
- rose / transparent
- Conductivity Conductivity
- dissipative
- Static decay time max. Static decay time max.
- 2 s
- Surface resistance Rs Surface resistance Rs
- < 1011 Ω
- amine-free amine-free
- yes
- Material Material
- polyethylene
- recyclable recyclable
- yes
- heat-sealable heat-sealable
- no
- Ambient temperature (storage conditions) Ambient temperature (storage conditions)
- >23 °C
- Humidity (storage conditions) Humidity (storage conditions)
- >20 %
- Shelf life Shelf life
- 3 years , when stored properly
- Auto-ignition temperature Auto-ignition temperature
- 420 °C
- Flash point Flash point
- 275 °C
- Melting point Melting point
- 116 °C
ESD protective
Electrostatic Discharge - marking for materials intended to protect other components from ESD by avoiding potential differences.
