Optical inspection systems

Optical inspection in ESD manufacturing is a crucial step in ensuring that electronic assemblies, components, and devices meet quality standards and are free of defects or errors. Discover our impressive range of vision inspection solutions! From state-of-the-art microscopes and advanced inspection systems to convenient magnifying lights and magnifiers, we provide you with the perfect tools to detect even the finest nuances.

The image shows a black magnifying glass with a flexible arm. The magnifying glass is round and has a clear lens. The arm is mounted on a stable, rectangular base.
ESD magnifier lamp TEVISIO RLLQ 48/2AR-ESD
Diopters: 3,5 / Swivel arm/frame: 384 / 400 mm /
LED Magnifier lamp TEVISIO RLLQ 48/2AR
Lens diameter = 160 mm / 3.5 diopters = x 1.88
Segment switching, articulated arm: 384 / 400 mm
ESD version/black, DIN EN 61340-5-1
!!! Table clamp not included!
dpvlink
16139

Product No.: 703.164.ESD
819,00 EUR
excl. 19% tax
The image shows a rectangular, flat object in dark gray, similar to a small box or cover, with a recess on one side. The surface is smooth.
Table base, black
Table base for ring LED magnifier lamp RLLQ 6
Color: black
dpvlink
3059

Product No.: 703.915
107,85 EUR
excl. 19% tax
The image shows a stable, flexible reading magnifier with a round, magnifying glass. It is attached to a long arm that is mounted on a base. Ideal for closer inspection.
VarioLED magnifier lamp 2.5x magnification
Diopters: 6 / Illuminant: LED / Magnification: 2.5x / Color temperature: 6,500 K / Swivel arm/frame: 900 mm
VarioLED magnifier lamp 27776 Eschenbach
Magnification 2.5x / lens diameter 132 mm /
6.0 diopters
Ring light with 84 high-performance LEDs, 3 steps
illuminance, max. 6000lx (200mm distance),
Incl. table clamp for plate thickness of 18-74 mm
pivot range of the magnifier head 180°
Mains connection 100V-240V / 50-60 Hz / 3m cable length
dpvlink
22908

Product No.: ES-27776
651,00 EUR
excl. 19% tax
The image shows a black magnifying lamp with a long, flexible arm. It is attached to a table and has a large, oval lens for magnifying objects.
Magnifier lamp W.A.V.E. LED / ESD UV
Diopters: 3,5 / Illuminant: UV-A LED / Magnification: 1.875x / Color temperature: 4,000 K /
ESD Magnifier lamp Wave with UV-A Licht,
with spring-loaded arm/clamp AH
ESD version, timer, dimmable 365nm
UVA LED modules, glass lens 3.5 diopter = x 1.88
Total extension 1050 mm, color black
dpvlink
17307

Product No.: 700.141.ESD.UV
615,00 EUR
excl. 19% tax
The image shows a microscope with two eyepieces, a stable stand, and an illuminated base. On it lies a small object for viewing. It is predominantly white.
LED stereo microscope
Magnification: 10x/20x / Working distance : 82-79
LED stereomicroscope 33213 Eschenbach
Magnification 10x / 20x
with LED incident light ring light and metal
stand
dpvlink
21099

Product No.: ES-33213
579,00 EUR
excl. 19% tax
The image shows a magnifying lamp on a flexible arm. The lens is round and has a transparent area in the center. The arm can be adjusted to various positions.
LED Magnifier lamp TEVISIO TVD 750/940/DM
Diopters: 3,5 / Swivel arm/frame: 384 / 400 mm
LED Magnifier lamp TEVISIO 750/940/DM
Lens diameter = 160 mm / 3.5 diopters = x 1.88
articulated arm: 384 / 400 mm, 3D head joint
Clear anodized aluminum / plastic black
!!! Table clamp not included!
dpvlink
16139

Product No.: 703.164
636,00 EUR
excl. 19% tax
The image shows a black C-clamp. It has a square top surface, a vertical bar, and a bottom surface with a screw for tightening.
Table clamp TK 1/65-ESD, 0-65 mm
Table clamp TK 1/65-ESD, clamping width 0-65 mm
Color: black
(for all Waldmann magnifier lamps)
dpvlink
3059

Product No.: 703.900.ESD
61,75 EUR
excl. 19% tax
The image shows a digital reading magnifier from Eschenbach. It has a black casing, a large, round lens, and LED lighting for better illumination of the reading material.
mobilux LED illuminated pocket magnifier 12.5-fold magnification
Magnification: 12.5x / Diameter / dimension [mm]: 35 / Lens: aspheric
mobilux LED illuminated pocket magnifier
151112 Eschenbach
Magnification 12.5x / lens Ø 35 mm / diopter 50
lightweight lens hard-coated on both sides
with case and 2 x batteries type AA
dpvlink
20788

Product No.: ES-151112
70,80 EUR
excl. 19% tax
The image shows a clip holding a transparent lens. The lens has a rounded shape and is attached to a black clip. It is used to enhance vision.
laboClip attachment magnifier 3x magnification
Magnification: 3x / Diopters: 7,75 / Lens: binocular / Working distance : 130
laboClip attachment magnifier 164630 Eschenbach
Magnification 3x / 7.75 dpt / working
distance 13 cm
Lens size: binocular 74.5 x 28 mm, Ø 40 mm
Incl. storage box
dpvlink
20822

Product No.: ES-164630
59,25 EUR
excl. 19% tax
The image shows a microscope on a stable base. It has two eyepieces for simultaneous viewing and several adjustable parts for focusing.
Stereo zoom microscope OZL 963 trinocular with telescopic arm
Stereo zoom microscope trinocular Kern OZL 963
Lens zoom 0.7x - 4.5x, magnification 7x - 45x
LED ring light, ECO universal stand

Scope of delivery:
- Stereo zoom microscope trinocular head
- ECO universal stand with plate
- holder
- ring light
- eyepieces 10x/ Ø 20 mm
- Dust protection cover
dpvlink
24087

Product No.: 401.OZL963
887,00 EUR
excl. 19% tax
The image shows a white microscope with two eyepieces and a movable arm. Below it, an illuminated object, probably a tiny detail, is clearly visible.
LED Stereo zoom microscope with metallic articulated arm
Magnification: 10x/20x / Working distance : 82-79
Stereomicroscope 33263 Eschenbach
Magnification 10x / 20x
with LED incident light ring light and metal
spring-joint arm
dpvlink
21101

Product No.: ES-33263
839,00 EUR
excl. 19% tax
The image shows a black magnifying glass with a flexible arm. The magnifying glass is round and has a clear lens. The arm is mounted on a stable, rectangular base.
ESD magnifier lamp TEVISIO RLLQ 48/2AR-ESD
Diopters: 3,5 / Swivel arm/frame: 484 / 500 mm /
LED Magnifier lamp TEVISIO RLLQ 48
Lens diameter = 160 mm / 3.5 diopters for x 1.88
anodized natural aluminum / plastic black
segment switching, frame length: 484 / 500 mm
ESD version, DIN EN 61340-5-1
!!! Table clamp mounting is not included in the scope of delivery !!!
dpvlink
16139

Product No.: 703.162.ESD
824,00 EUR
excl. 19% tax
The image displays an electronic magnifying glass. It features a rectangular lens surrounded by a black and white casing. On the side, there is a control panel with buttons.
mobilux LED illuminated pocket magnifier 4-fold magnification 75x50mm
Magnification: 4x / Diameter / dimension [mm]: 75 x 50 / Lens: aspheric
mobilux LED illuminated pocket magnifier
15114 Eschenbach
Magnification 10x / 75 x 50 mm / diopter 16.0
white-light LED 52 mA
lightweight lens hard-coated on both sides
with case and 2 x batteries type AA
dpvlink
20788

Product No.: ES-15114
83,25 EUR
excl. 19% tax
The image shows a simple, white tool part with a conical shape, attached to a metal bolt. It has a central opening and a screw for attachment.
AH fixing clamp
AH fixing clamp kit (for LFM 101/102, WAVE,
FL 101) clamping width 60 mm
Color: light grey
dpvlink
11187

Product No.: 700.128.AH.GR
13,30 EUR
excl. 19% tax
The image displays a round, flat object in soft, light colors. It has a slightly curved surface and a small indentation on the side. It might be a lid or a cover.
Mobilent folding magnifier 7x magnification
Magnification: 7x / Diameter in mm: 35 / Diopters: 28
Mobilent folding magnifier 171097 Eschenbach
Magnification 7x / lens Ø 35 mm / 28.0 diopters
LED lighting, precisely manufactured aspheric
lens, plastic housing dustproof, lanyard
Color: White
dpvlink
20840

Product No.: ES-171097
25,70 EUR
excl. 19% tax
The image shows a magnifying lamp on a flexible arm. The lens is round and has a transparent area in the center. The arm can be adjusted to various positions.
LED Magnifier lamp TEVISIO TVD 750/940/DM + additional lens 8 diopters
Diopters: 3,5 / 8 / Swivel arm/frame: 384 / 400 mm
LED magnifier lamp TEVISIO TVD 750/940/DM
Lens diameter 160 mm /3.5 diopters = x1.88
fixed addtional lens 8 diopters, articulated arm:
384/400 mm, 3D head joint,
colorless anodized aluminium / plastic black
!!! Table clamp not included in the scope of delivery !!!!
dpvlink
16139

Product No.: 703.165
642,00 EUR
excl. 19% tax
33 to 48 (from a total of 185)
