Diagonal cutting pliers RX8131
The RX8131 side cutter by Lindström, developed as part of the ERGO™ process, is distinguished by its high-precision functionality and ergonomic design. This tool features oval jaws and is made from a high-performance steel alloy that achieves a Rockwell hardness of 63-65 HrC. The cutting edges are induction-hardened and provide excellent cutting angle accuracy and contact thanks to numerically controlled machine grinding.
The handles are made from a synthetic dual-component material that combines a thermoplastic surface on hard polypropylene to ensure optimal grip. Additionally, the handles are ESD-safe, making them particularly suitable for precise electronic work. The built-in opening spring can be adjusted to three positions or removed to regulate tension during use.
With an overall length of 133.5 mm and a weight of 68 g, the side cutter offers a handy and efficient solution for cutting copper wire and other soft to medium-hard materials. The cutting capacity extends up to a diameter of 2.0 mm for soft materials and 1.02 mm for medium-hard materials. The head shape is oval with a head width of 8 mm and a jaw length of 8.5 mm, allowing for precise cuts.
This tool is ideal for detailed work on wiring harnesses and circuit boards, offering long-lasting durability and reliability through its high-quality craftsmanship and material selection.
The handles are made from a synthetic dual-component material that combines a thermoplastic surface on hard polypropylene to ensure optimal grip. Additionally, the handles are ESD-safe, making them particularly suitable for precise electronic work. The built-in opening spring can be adjusted to three positions or removed to regulate tension during use.
With an overall length of 133.5 mm and a weight of 68 g, the side cutter offers a handy and efficient solution for cutting copper wire and other soft to medium-hard materials. The cutting capacity extends up to a diameter of 2.0 mm for soft materials and 1.02 mm for medium-hard materials. The head shape is oval with a head width of 8 mm and a jaw length of 8.5 mm, allowing for precise cuts.
This tool is ideal for detailed work on wiring harnesses and circuit boards, offering long-lasting durability and reliability through its high-quality craftsmanship and material selection.
Details
- Bevel Bevel
- small bevel
- Head type/size Head type/size
- extra small
- Max Ø soft Max Ø soft
- 2.0 mm
- Max Ø medium Max Ø medium
- 1.02 mm
- Version Version
- with safety spring
- Head thickness Head thickness
- 5 mm
- Length [mm] Length [mm]
- 133.5 mm
- Material Material
- steel
- Stick material Stick material
- PP
- Surface Surface
- brilliant
- ESD ESD
- yes
- Head shape Head shape
- oval
- Head width Head width
- 8 mm
- Jaw length Jaw length
- 8.5 mm
- Type of pliers Type of pliers
- Diagonal cutting pliers
- Weight Weight
- 68 g
Show accessories
ESD protective
Electrostatic Discharge - marking for materials intended to protect other components from ESD by avoiding potential differences.
Small bevel
Standard bevel. Almost smooth, flush cut. Applicable for soft and medium-hard steel wires and copper wires.
Accessories
Downloads
- Please log in to download datasheets! :
- There are several datasheets for this product. Please log in!
Catalogues
Product Family
Article image
Article description
Bevel
Head type/size
Max Ø soft
Max Ø medium
Max Ø hard
Version
Price
Compare
small bevel
small
2.0 mm
1.25 mm
0.5 mm
with safety spring
without bevel
small
2.0 mm
1.02 mm
with safety spring
large bevel
large
2.0 mm
2.0 mm
0.8 mm
with safety spring
large bevel
small
2.0 mm
1.25 mm
0.5 mm
with safety spring
without bevel
regular
2.0 mm
1.25 mm
with safety spring
without bevel
extra small
2.0 mm
0.8 mm
with safety spring
large bevel
extra small
2.0 mm
1.02 mm
with safety spring
small bevel
extra small
2.0 mm
1.02 mm
with safety spring
large bevel
regular
2.0 mm
1.6 mm
0.8 mm
with safety spring
small bevel
regular
2.0 mm
1.6 mm
0.8 mm
with safety spring
small bevel
large
2.0 mm
2.0 mm
0.8 mm
with safety spring
without bevel
large
2.0 mm
1.6 mm
with safety spring
