End cutting pliers 3784
End Cutter 3784
The End Cutter 3784 is distinguished by its special design for cutting through hard materials such as wire, nails, or thin metal rods. This tool is ideal for use in electronics manufacturing, craftsmanship, and metal processing, as it provides precise cutting performance. The end cutter is made from a special alloyed steel, drop-forged, hardened, and tempered to ensure exceptional strength and durability.
Technical Specifications: - Precise through-bolted joint construction for permanent, adjustment-free jaw alignment. - Induction-hardened jaws for outstanding long-term performance. - High-gloss polished surface with no risk of flaking chrome. - Spot-welded double leaf springs for consistent action. - Ergonomically shaped two-component handles for comfort and control. - Fully ESD compliant, according to IEC 61340 5.1 and 5.2. - Tapered head for precise work. - Length: 130 mm, head thickness: 6 mm, jaw length: 20 mm, head width: 10 mm. - Material: steel, surface: polished.
With its small bevel, the End Cutter 3784 is suitable for hard and soft steel wires as well as soft materials like copper wire and cables.
Item number: 3784DF
The End Cutter 3784 is distinguished by its special design for cutting through hard materials such as wire, nails, or thin metal rods. This tool is ideal for use in electronics manufacturing, craftsmanship, and metal processing, as it provides precise cutting performance. The end cutter is made from a special alloyed steel, drop-forged, hardened, and tempered to ensure exceptional strength and durability.
Technical Specifications: - Precise through-bolted joint construction for permanent, adjustment-free jaw alignment. - Induction-hardened jaws for outstanding long-term performance. - High-gloss polished surface with no risk of flaking chrome. - Spot-welded double leaf springs for consistent action. - Ergonomically shaped two-component handles for comfort and control. - Fully ESD compliant, according to IEC 61340 5.1 and 5.2. - Tapered head for precise work. - Length: 130 mm, head thickness: 6 mm, jaw length: 20 mm, head width: 10 mm. - Material: steel, surface: polished.
With its small bevel, the End Cutter 3784 is suitable for hard and soft steel wires as well as soft materials like copper wire and cables.
Item number: 3784DF
Details
- Type of pliers Type of pliers
- End cutting pliers
- Bevel Bevel
- small bevel
- Length [mm] Length [mm]
- 130 mm
- AWG medium AWG medium
- 22
- AWG soft AWG soft
- 20
- Max Ø medium Max Ø medium
- 0.6 mm
- Max Ø soft Max Ø soft
- 0.8 mm
- Head thickness Head thickness
- 6 mm
- Blade length Blade length
- 4
- Material Material
- steel
- Surface Surface
- polished
- ESD ESD
- yes
- Head shape Head shape
- tapered
- Head width Head width
- 10 mm
- Jaw length Jaw length
- 20 mm
The current composition of shape and technology, completely convincing.
A flowing line adapted to the natural form of the hand in the right proportions.
The guarantee for a fatigue-free, controlled, safe and fast working in a level of quality that has been unknown up to now.
Ergonomics in an optimum design.
- Two-component handle with flush, soft thermoplastic material, slip-resistant and comfortable.
- Slip protection for a controlled and concentrated work.
- Captive, welded double leaf spring: guarantees an optimal function for the whole service life.
- Precise box joint: accurate guiding of the jaws without readjustment in case of a long service life.
- Mirror polish: optimal protection against corrosion without chrome, easy to clean.
- Inductive hardening of cutting edges: high hardness for a long durability.
The shapes of cutting edges and cutting performance
With small bevel (facet)
Normal cut. Suitable for cutting hard and soft steel wires as well as soft materials such as copper wire and cable.
With large bevel (facet)
Suitable for cutting hard and very hard steel wires. Long service life.
Without bevel (facet)
Flush cut. Extremely sharp cutting edges. Only suitable for soft steel wires, copper wire and cable.
Made in Germany
Small bevel
Standard bevel. Almost smooth, flush cut. Applicable for soft and medium-hard steel wires and copper wires.
