The image shows a tattoo device with a silver and black casing. It has an orange attachment and a long cable connection. The shape is slim and ergonomic.
WXDP 120 desoldering iron 120 W
(Product No.: 513.201.99)
The image shows a tattoo device with a silver and black casing. It has an orange attachment and a long cable connection. The shape is slim and ergonomic.
Notice

WXDP 120 desoldering iron 120 W

WXDP 120 desoldering iron 120 W

dpvlink:
16463
Properties:
Further product information

available available
313,00 EUR

excl. 19% tax

1 PCE
Compare Compare
Notice
Product Info

WXDP 120 desoldering iron 120 W

The WXDP 120 desoldering iron from Weller is a high-performance solution for professional rework applications in electronics. With a power of 120 W and a rapid heating time of only 35 seconds, even directly from standby mode, this tool is particularly efficient in demanding situations. The desoldering iron is ESD-safe and operates in a temperature range from 100 to 450 °C, making it suitable for a variety of soldering and desoldering tasks.
The appropriate soldering tips from the XDS series complement the WXDP 120 and ensure precise results. An integrated data storage allows for the storage of individual soldering and desoldering parameters directly on the device, increasing flexibility without constant reconfiguration. A handy finger switch activates the vacuum and an extended nozzle shaft prevents the suction tube from clogging. Additionally, an LED ring light provides visual control of the soldering process.
The innovative Stop + Go function with usage sensor and the option for individual iron calibration, independent of the base station, highlight the user-friendliness and technical sophistication of the WXDP 120.
Power
Power
120 W
ESD
ESD
yes
suitable soldering tip series
suitable soldering tip series
XDS
Heating-up time
Heating-up time
35 s
Temperature range
Temperature range
100 - 450 °C
Pictograms
ESD protective
Electrostatic Discharge - marking for materials intended to protect other components from ESD by avoiding potential differences.

Documents

Downloads

Please log in to download datasheets! :
There are several datasheets for this product. Please log in!

Catalogues

Page: 605
Complete Catalog 2023 - 2024

Product Family

WXDP 120 - Set

Article image
Article description
Power
ESD
suitable soldering tip series
Heating-up time
Temperature range
included soldering iron
Safety rest
Price
Compare
513.201.99 - WXDP 120 desoldering iron 120 W
513.201.99
WXDP 120 desoldering iron 120 W
120 W
yes
XDS
35 s
100 - 450 °C


313,00 EUR
513.202.99 - WXDP 120 Set
513.202.99
WXDP 120 Set
120 W
yes
XDS / XDSL
35 s
100 - 450 °C
WXDP 120
WSR 207
374,25 EUR
Show Compare List (0)
