The image shows a light blue soldering station. It features a digital display, buttons, and a cable connected to a wooden soldering iron. The iron has a handle-like shape.
WXSF 120 Feeding unit
(Product No.: 513.911.99)
The image shows a light blue soldering station. It features a digital display, buttons, and a cable connected to a wooden soldering iron. The iron has a handle-like shape.
Notice

WXSF 120 Feeding unit

WXSF 120 Feeding unit

dpvlink:
19251
Properties:
Further product information

at short notice at short notice
1.600,00 EUR

excl. 19% tax

1 PCE
Compare Compare
Notice
Product Info

WXSF 120 Feeding unit

WXSF 120 Feed Unit
The WXSF 120 feed unit combines a high-performance 120W soldering iron function with an automatic solder wire feed for precise and efficient manual soldering processes. This unit is ideal for working on circuit boards, wiring harnesses, connectors, or switches and improves soldering quality through a precise and preset solder supply. The adhesive-coated inner sides of the feed tube prevent the flux from sticking and reduce maintenance costs. Additionally, the device offers a start-stop/standby function as well as the choice between pulse or timer mode.

Technical Specifications:
  • Power: 120 W
  • Total weight (without solder wire): 1.0 kg
  • Max. solder roll weight: 1 kg
  • Solder wire diameter: 0.5 - 1.0 mm
  • Feed: 1 - 27.5 mm/s
  • Heating time: 14 s
  • Temperature range: 90 - 450°C

    Suitable for soldering stations WX 1, WX 2, WXA 2, WXD 2, WXR 3.
    • Feeding per second
    Feeding per second
    1 - 27.5 mm
    Soldering wire
    Soldering wire
    0.5 - 1.0 mm
    Heating-up time
    Heating-up time
    14 s
    Pictograms
    ESD protective
    Electrostatic Discharge - marking for materials intended to protect other components from ESD by avoiding potential differences.

    Documents

    Downloads

    Please log in to download datasheets! :
    There are several datasheets for this product. Please log in!

    Catalogues

    Page: 611
    Complete Catalog 2023 - 2024

    Product Family

    FlowinSmart wire feeding system

    Article image
    Article description
    Feeding per second
    Soldering wire
    Heating-up time
    Price
    Compare
    513.906.99 - WTSF 80 Feeding unit
    513.906.99
    WTSF 80 Feeding unit
    1 - 27.5 mm
    0.5 - 1.0 mm
    10 s
    1.253,00 EUR
    513.911.99 - WXSF 120 Feeding unit
    513.911.99
    WXSF 120 Feeding unit
    1 - 27.5 mm
    0.5 - 1.0 mm
    14 s
    1.600,00 EUR
